Basic Information
Model NO.: 8 1/2"
Certification: API, ISO 9001
Type: Non core drill bit
Use: Well Drilling, oil and gas drilling
Process: Sintering
Hole Diameter: 215.9mm
Rpm: 120-50
HS Code: 82071990
Customized: Customized
Length: Taper-length
Material: Tungsten Carbide
Number of Shaft: 3
Structure: Deep Hole Drilling
Condition: New
Wob: 0.4-1.0kn/mm
Origin: Shaanxi, China
Product Description
We guaranteed products at a competitive price and high quality. At present, our products have a very good sale in domestic and overseas market. We wish to cooperate with you to create a bright future and mutual benefit. Much appreciation for your prompt attention in advance, we are eager to look forward to hearing from you soon.
Rubber sealed sliding bearing bits are sealed by special type "o". Under the normal rotary speed conditions, they can stand high bit pressure. The bore surface of the cone has been treated with special techniaue in order to improve sliding motion of the bearing. And every performance is improved greatly.
1 O-shape seal ring with high saturation butadience acrylonitrile rubber improved the bearing sealed reliability.
2 To adapt high strength and toughness hard alloy teeth, the shock resistance has been increased and the breakage rate has been decreased.
3 The bearing contact surface, neck journal of jaw have been adapted to wear resistance alloy materials, the special craft processing has been applied in the bore surface of the cone which increases the load capability and the working life.
4 Optimized tooth number of cone and height of tungsten carbide tooth which improved the total cutting property and drilling footage.
5 High-performance lubricant grease has been applied in bearing which increased lubricating and protecting.
